Physical Length: 290 mm (11.4 in.) Width: 189 mm (7.4 in.) Height: 360 mm (14.2 in.) Weight: 7.1 kg (15.7 lbs.) Dynamic Effects Color mixing: RGBW Color presets: 36 color presets plus full white, ‘color wheel’ effects Electronic dimming: 0 - 100%, four dimming curve options Strobe and pulse effects: Variable speed and action, random strobe Electronic 'shutter' effect: Instant open and blackout Zoom: Motorized Pan: 540° Tilt: 200° Control and Programming Control options: DMX DMX channels: 14 White balance control: RGB adjustment 16-bit fine control: Dimming, pan and tilt DMX address setting: Control panel with LCD display DMX compliance: USITT DMX512/1990 Optics Light source: 12 x 10 W RGBW Osram Ostar LEDs Minimum LED lifetime: 50 000 hours (to >70% luminous output)* Zoom range: 10° - 60° *Figure obtained under manufacturer's test conditions Construction Color: Black Housing: High-impact flame-retardant thermoplastic Ingress protection rating: IP20 Installation Mounting points: One quarter‐turn bracket for rigging clamp Location: Indoor use only, must be fastened to surface or structure Orientation: Any Minimum distance to illuminated surfaces: 200 mm (8 in.) Minimum distance to combustible materials: 100 mm (4 in.) Minimum clearance around fans and vents: 100 mm (4 in.) Connections AC power in/thru: Neutrik PowerCon DMX data in/thru: 3-pin and 5-pin locking XLR
Related Items RUSH™ Software Uploader 1: P/N 91611399 Ordering Information RUSH MH 6 Wash™ in cardboard box: P/N 90280080 | Electrical AC power: 100-240 V nominal, 50/60 Hz Power supply unit: Auto-ranging electronic switch mode Fuse: T 3.15 A Recommended Miniature Circuit Breaker*: Type D *Per IEC 60898/UL489/CSA C22.2 No. 5 Power consumption figures are typical, not maximum. Allow for +/-10% variation. Typical Power and Current 120 V, 60 Hz: 1.3 A, 150 W, PF 0.99 230 V, 50 Hz: 0.7 A, 150 W, PF 0.94 Typical half-cycle RMS inrush current at 240 VAC: 11.3 A Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. Thermal Cooling: Forced air (temperature-regulated, low noise) Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 0° C (32° F) Approvals EU safety: EN 60598-2-17 (EN605989-1), EN 62471, EN 62493 EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety: UL 1573, UL 8750 US EMC: CFR Title 47 Part 15 Canadian safety: CSA C22.2 No. 166 Australia/NZ: C-TICK N4241 / RCM Included Items Power input cable, 6 A, 18 AWG, UL, 0.75 mm2, H05VV-F, 1.5 m (4.9 ft.), without mains plug Omega bracket for rigging clamp attachment Accessories Cables Power input cable, AWG 14, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon input connector, 3 m (9.8 ft.): P/N 11541508 Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 1.4 m (4.6 ft.): P/N 11541509 Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 2.25 m (7.4 ft.): P/N 11541510 Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 3.25 m (10.7 ft.): P/N 11541511 Power connectors Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: P/N 05342804 Neutrik PowerCon NAC3FCB power output connector, cable mount, light grey: P/N 05342805 DMX link DMX termination plug, 3-pin male XLR: P/N 91613017 Installation hardware Half-coupler clamp: P/N 91602005 G-clamp: P/N 91602003 Quick-trigger clamp: P/N 91602007 Safety cable, safe working load 50 kg: P/N 91604003 |
