Dual 1-inch, externally biased, ultra-thin, 2.5 micron, 24-karat gold-layered, low mass, Mylar® diaphragms provide superior transient response
Multiple polar patterns: cardioid, omnidirectional and bidirectional–for maximum flexibility in a wide variety of applications
Prethos™ Advanced Preamplifer Technology: provides transparency, extremely fast transient response and no crossover distortion, minimizes harmonic and intermodulation distortions
Groundbreaking self-noise specifications: 4 dB (cardioid), 6 dB (omnidirectional), 7.5 dB (bidirectional)
Full-range frequency response (20 Hz - 20 KHz) for an extremely accurate reproduction of voice and instruments
Highly consistent polar patterns
Premium electronic components and gold-plated internal and external connectors
Subsonic filter eliminates rumble from mechanical vibration below 17 Hz
15 dB attenuation switch for handling high input SPL sound sources
3-position switchable low-frequency filter virtually eliminates unwanted background noise and controls proximity effect
Durable zinc die-cast housing and hardened low carbon steel grille to protect the cartridge from accidental drops or misuse
An integrated three-stage pop protection grille to guard against wind and breath noise
An internal shock mount to reduce unwanted handling and stand noise
|
Weight: 492 g
Height x Width x Depth: 187.0 × 55.9 × 55.9 mm
Frequency Response: 20 Hz – 20 kHz
Frequency Response: Flat
Sensitivity: -37.00 dBV/Pa – 14.80 mV/Pa
Self-Noise: Cardioid: 4 dB(A), Omnidirectional: 6 dB(A), Bidirectional: 7,5 dB(A)
Max. Sound Pressure Level:
Omnidirectional: 140 dB / (pad on): 152 dB
Cardioid: 134 dB / (pad on): 150 dB
Bidirectional: 139 dB / (pad on): 151 dB
Transducer Type: Condenser
Polar Pattern: Bidirectional, Cardioid, Omnidirectional
Switchable low cut: ✔
Connectors: 3 Pin XLR
Attenuator: ✔
Main Functionality: Performance
Requires Phantom Power: 11 to 52 VDC Cartridge: Fixed
|
Sensitivity ( open circuit voltage, @ 1 kHz, typical)
Cardioid: –31 dBV /Pa (29.8 mV)
Omnidirectional: –37 dBV /Pa (14.8 mV )
Bidirectional: –36 dBV /Pa (16.8 mV)
Self Noise (equivalent SPL,A-weighted , typical)
Cardioid: 4 dB SPL -A
Omnidirectional: 6 dB SPL -A
Bidirectional: 7.5 dB SPL -A
Signal-to -Noise Ratio
Cardioid: 90 dB
Omnidirectional: 88 dB
Bidirectional: 86.5 dB
|
