Sennheiser EW 500 G4-945-AS Kablosuz El Mikrofonu
Sennheiser EW 500 G4-945-AS, gelişmiş güvenilirlik ve kontrol için profosyonel düzeyde özelliklere sahip, kullanımı kolay, rafa monte edilebilir kablosuz el mikrofonu sistemidir. eğişken RF gücü, olağanüstü geniş bir ayar aralığı, çok kanallı kurulumlar için Ethernet ağı ve OLED ekran ve jog tekerleği ile sezgisel bir arayüz sunar. Sistem, iş ve eğitim ortamlarında, ibadethanelerde, tiyatrolarda veya müzik sahnelerinde çalışan sunuculara, din adamlarına, öğretim görevlilerine ve sanatçılara yüksek kaliteli ses sağlar.
Ürüne en uygun fiyat garantisi ile MeduMuzikMarket.com adresimizden ulaşarak satın alabilirsiniz..
Özellikleri
Renowned sound engineers rely on ew 500 G4's flexibility, especially when handling multi-channel settings on the world's music stages. Up to 88 MHz bandwidth, up to 32 channels. Ethernet connection for Wireless Systems Manager (WSM) control software included for advanced frequency coordination in multi-channel setups.
True diversity half-rack receiver in a full-metal housing with intuitive OLED display for full control
Easy and flexible wireless synchronization between transmitter and receiver via infrared
Up to 32 compatible channels
Up to 88 MHz bandwidth with 3520 selectable frequencies, fully tunable in a stable UHF range
Ethernet connection for Wireless Systems Manager (WSM) control software for advanced frequency coordination in multi-channel setups
High RF output power (up to 50 mW, adjustable in three steps 10/30/50) depending on country regulations
Frequency range
AS: 520 - 558 MHz
Aw+: 470 - 558 MHz
Bw: 626 - 698 MHz
Cw: 718 - 790 MHz
Dw: 790 - 865 MHz
GBw: 606 - 678 MHz
Gw: 558 - 626 MHz
Gw1: 558 - 608 MHz
K+: 925 - 937,5 MHz
Dimensions
Approx. 202 x 212 x 43 mm
Compander
Sennheiser HDX
THD, total harmonic distortion
≤ 0.9 %
Weight
Approx. 980 g
Audio output
6.3 mm jack socket (unbalanced): +12 dBu
XLR socket (balanced): +18 dBu
Signal-to-noise ratio
≥ 115 dBA
Switching bandwidth
up to 88 MHz
Peak deviation
±48 kHz
Nominal deviation
±24 kHz
Modulation
Wideband FM
Power supply
12 V DC
Antenna connector
2 BNC sockets
Current consumption
350 mA
Adjacent channel rejection
Typically ≥ 75 dB
Intermodulation attenuation
Typically ≥ 70 dB
Receiving frequency
Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
RF sensitivity
< 2.5 μV for 52 dBA eff S/N
Squelch
5 to 25 dBμV in steps of 2 dB
Equalizer
Preset 1: Flat
Preset 2: Low Cut (-3 dB at 180 Hz)
Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)
Preset 4: High Boost (+6 dB at 10 kHz)
Temperature Range
-10 °C to +55 °C
Receiver Principle
True diversity
Blocking
≥ 75 dB
