Profesyonel Canlı Muzik Sistemi Hazır Fırsat Paketi
Paket İçeriği
2 Adet dB Technologies B-Hype 15 Hoparlör
1 Adet Soundcraft Signature 10 Mikser
dB Technologies B-Hype 15 Hoparlör
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Usable Bandwidth: [-10dB]51 - 20.000 Hz
Frequency Response: [-6 dB]57 - 19.700 Hz
Max SPL: 126.5 dB
Type HF: Compression Driver
HF voice coil: 1 "
LF: 15 "
LF voice coil: 2 "
Crossover Frequency: 2100 Hz (24 dB/oct.)
Horizontal Dispersion: asymmetrical 85° up / 120°down
Vertical Dispersion: 85° (+25/ -60°)
Amplifier
Amp Technology: Custom Made
Amp Class: Class D - Passive cooling (convection)
Power Peak: 400 W
RMS Power: 200 W
Processor
Controller: DSP 28/56 bit- 48 kHz
Limiter: Peak, RMS, Thermal
Controls: Volume, Audio Input Sensitivity, DSP Preset
Input
Main Connection: VDE
Signal Input: Balanced 1xCombo IN (MIC/LINE)
SIGNAL Out: (Balanced) 1xXLR OUT (LINK)
Mechanics
Housing: Polypropylene
Grille: Full Metal Grille
Handles: 3 (2 on side 1 on top)
Pole Mount: 36 mm
Width: 415 mm (16.34 in)
Height: 725 mm (28.54 in)Depth: 391 mm (15.39 in)
Weight: 17.4 kg (38.36 lb)
Angles Up: Double wedge angle 45°
Soundcraft Signature 10 Mikser
6 XLR Mono+2 St Giriş
Enstrüman Hi-Z Giriş
3 AUX
Lexicon MPX Efekt
DBX comp/Limiter
Genişletilmiş kanal Eq,48 V
USB Kayıt ve Okuma
GB SERİSİ TON KATLAR
High-Performance 10-input small format analogue mixers with onboard effects
Iconic Soundcraft® Ghost mic preamps with ultra-low noise performance
Renowned Soundcraft® Sapphyre British EQ with sweepable mid-bands per channel
Lexicon® Effects Engine featuring award-winning Reverbs, Delays, Choruses and Modulations
dbx® Limiters (High-ratio Compressors) on input channels
2-in/2-out USB audio playback and recording
Switchable Hi-Z inputs for guitars, basses and other instruments
Hi-Pass Filters (low-cut) and 48V Phantom Power on all mic channels
Comprehensive Soundcraft® GB Series audio routing
Smooth premium-quality faders
Robust metal construction for tour-grade build quality and reliability
Internal universal power supply
Channels 10
Preamps 6 x Ghost
Equalization Soundcraft Sapphyre EQ: 3-band (1 band of swept mids)
Input Limiter dbx: 2
Effects Lexicon: Single engine
USB Interface 2 x input
2 x output
Auxiliary 3
Subgroup Outputs none
Faders 2" (60 mm)
