Physical Dimensions (L x W x H): 327 x 312 x 207 mm (12.8 x 12.3 x 8.1 in.) Weight: 4 kg (8.8 lbs.) Dynamic Effects Dimming: 0 – 100%, coarse & fine control Shutter: Strobe & pulse effects, instant open and blackout Control and Programming Control system: USITT DMX512/1990 with RDM DMX channels: 3 RDM compliance: ANSI/ESTA E.120 Interface: Control panel with backlit LCD display Construction Color: Black Housing: Cast aluminum IP rating : IP 20 Installation Mounting points : Adjustable bracket, surface or truss mount Location: Indoor location only Orientation: Any Minimum distance to illuminated surfaces: 0.5 m (20 in.) Minimum distance to combustible materials: 0.1 m (4 in.) Connections AC power input/output: Neutrik PowerCon DMX & RDM data in/out : 5-pin locking XLR RUSH PAR 4 UV User Manual 31 Related Items Martin M-DMX with Martin Companion Uploader Software Power connectors Power Connector PowerCON Male: P/N 91611795
Power Connector PowerCON Female : P/N 91611794 |
Electrical AC power: 100-240 V nominal, 50/60 Hz Power supply unit: Auto-ranging electronic switch mode Maximum total power consumption: 114 W Typical half-cycle RMS inrush current: 11.2 A Recommended Miniature Circuit Breaker when power linking* : Type D *Per IEC 60898/UL489/CSA C22.2 No. 5 Typical Power and Current 100 V, 60 Hz: 114 W, 1.2 A, PF 1.000 120 V, 60 Hz: 114 W, 1.0 A, PF 0.996 230 V, 50 Hz: 114 W, 0.5 A, PF 0.933 Measurements made at nominal voltage. Figures are typical, not maximum, allow for a deviation of +/- 10%. Thermal Cooling: Forced air, temperature-regulated Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min): 0°C (32° F) Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493 EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety: UL 1573 US EMC: 47 CFR 15 Class A Canadian safety : CSA C22.2 No. 166 Canadian EMC : ICES-003 Class A Australia/NZ: RCM CE ETL C US Intertek Aus Included Items Power cable, 1.5 m without mains plug |
