Physical Length: 266 mm (10.5 in.) Width: 287 mm (11.3 in.) Height: 329 mm (13.0 in.) Weight: 5.5 kg (12.2 lbs.) Dynamic Effects Color mixing: RGBW Color selection: 33 color presets plus full white, 'color wheel' effects Electronic dimming: 0 - 100% Strobe and pulse effects: Variable speed and action, random strobe Electronic 'shutter' effect: Instant open and blackout Zoom: Motorized Control and Programming Control options: DMX, stand-alone scene DMX channels: 5/9 White balance control: RGB adjustment DMX address setting: Control panel with LCD display Stand-alone programming: Control panel with LCD display Protocol: USITT DMX512/1990 Optics Light source: 12 x 10 W RGBW Osram Ostar LEDs Zoom range: 10° - 60° Minimum LED lifetime: 50 000 hours (to >70% luminous output)* *Figure obtained under manufacturer's test conditions Construction Housing: Aluminum Color(s): Black Protection rating: IP20 Installation Mounting: Adjustable bracket, surface or truss mount Orientation: Any Location: Indoor use only Connections AC power in/thru: Neutrik PowerCon DMX data in/thru: 5-pin XLR Related Items RUSH Software Uploader 1™: P/N 91611399 Ordering Information RUSH PAR 2 RGBW Zoom™ in cardboard box: P/N 90480040 |
Electrical AC power: 100-240 V nominal, 50/60 Hz Typical total power consumption: 151 W Power consumption figures are typical, not maximum. Allow for +/-10% variation. Typical Power and Current 120 V, 60 Hz: 1.3 A, 151 W, PF 0.993 230 V, 50 Hz: 0.7 A, 148 W, PF 0.961 Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. Thermal Cooling: Forced air (temperature-regulated, low noise) Maximum ambient temperature (Ta max.): 40° C Minimum ambient temperature (Ta min.): 0° C Total heat dissipation (calculated, +/- 10%, at full intensity, full white): 520 BTU/hr. Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493 EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety (pending): UL 1573 US EMC: 47 CFR Part 15 Class A Canadian safety (pending): CSA C22.2 No. 166 Canadian EMC: ICES-003 Class A Australia/NZ: C-TICK N4241 Included Items Power cable 1.5 m Mounting bracket Accessories Gel Frame for RUSH PAR 2 (set of 10): P/N 46000106 Cables, 16 A, for connection to power in chains Power input cable, 14 AWG, UL, SJT, 1.5 mm2; H05VV-F, with PowerCon input connector, 3 m (9.9 ft.): P/N 11541508 H05VV-F, with PowerCon input connector, 1.4 m (4.6 ft.): P/N 11541509 H05VV-F, with PowerCon input connector, 2.25 m (7.4 ft.): P/N 11541510 H05VV-F, with PowerCon input connector, 3.25 m (10.7 ft.): P/N 11541511 Power connectors Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: P/N 05342804 Neutrik PowerCon NAC3FCB power output connector, cable mount, light grey:P/N 05342805 DMX link DMX termination plug, 3-pin male XLR: P/N 91613017 Installation hardware G-clamp: P/N 91602003 Half-coupler clamp: P/N 91602005 |
