Physical Length: 275 mm (10.8 in.) Width: 188 mm (7.4 in.) Height: 325 mm (12.8 in.) Weight: 7.5 kg (16.5 lbs.) Dynamic Effects Beam color mixing: RGBW Ring color mixing: RGB, grouped or individual control of 24 cells Virtual color wheel: 33 color presets, virtual color wheel rotation effects, random color (independent in beam and ring) Pre-programmed effects: FX (effect macros) in ring with variable speed and direction of sequences, synchronization and chases across multiple fixtures Dimming: 0-100%, coarse and fine control (independent in beam and ring) Electronic shutter effect: Strobe effect, pulse effects, instant open and blackout (independent in beam and ring) Pan: 540° Tilt: 270° Pan and tilt rotation effect: Constant, variable speed and direction Control and Programming Control options: DMX, RDM, stand-alone, master/slave DMX channels: 24 or 93 Stand-alone trigger options: Music trig, auto trig Setting and addressing: Control panel with backlit LCD display Pan and tilt speed: Adjustable via onboard control panel and DMX DMX compliance: USITT DMX512/1990 RDM compliance: ANSI/ESTA E1.20 Optics Beam effect light source: 60 W RGBW Osram LE RTDUW S2WP Ring effect light source: 24 x 0.25 W RGB LEDs Cutoff beam angle: 4.4° Minimum LED lifetime: 20 000 hours to >70% luminous output* *Under manufacturer's test conditions Construction Color: Black Housing: High-impact flame-retardant thermoplastic Protection rating: IP20 Installation Mounting points: Two quarter-turn omega brackets for rigging clamps Location: Indoor use only, must be fastened to surface or structure Orientation: Any Minimum distance to illuminated surfaces: 200 mm (8 in.) Minimum distance to combustible materials: 100 mm (4 in.) Minimum clearance around fans and air vents: 100 mm (4 in.) Connections AC power in, thru: Neutrik TRUE1 DMX data in, thru: 3-pin and 5-pin locking XLR | Electrical AC power: 100-120 / 200-240 V nominal, 50/60 Hz Power supply unit: Auto-ranging electronic switch mode Typical Power and Current 120 V, 60 Hz 0.85 A, 100W, PF 0.99 230 V, 50 Hz 0.49 A, 108W. PF 0.99 Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. Thermal Cooling: Forced air (temperature-regulated, low noise) Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 0° C (32° F) Total heat dissipation (calculated, +/- 10%, at full intensity, full white): 1300 BTU/hr. Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493 EU EMC: EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3 US safety: UL 1573 US EMC: CFR Title 47 Part 15 Class A Canadian safety: CSA C22.2 No. 166 Canadian EMC: ICES-003 Class A Australia/NZ (pending): RCM Included Items Power cable, 1.5 m (4.9 ft.), without mains plug Accessories Cables, 16 A, for connection to power Power input cable, H07RN-F, 2.5 mm², 14 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91611797 Power input cable, H07RN-F, 2.5 mm², 14 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91611786 Power input cable, SJOOW, 12 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91610173 Power input cable, SJOOW, 12 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91610174 Cables, 16 A, for relaying power in chains Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 0.45 m (1.5 ft.): P/N 91611784 Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 1.2 m (3.9 ft.): P/N 91611785 Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91611796 Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 0.45 m (1.5 ft.): P/N 91610170 Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 1.2 m (3.9 ft.): P/N 91610171 Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91610172 Connectors Power connector, cable mount, Neutrik TRUE1 NAC3FX-W (female): P/N 91611789 Power connector, cable mount, Neutrik TRUE1 NAC3MX-W (male): P/N 91611788 Installation hardware G-clamp (installation hanging vertically downwards only): P/N 91602003 Half-coupler clamp: P/N 91602005 |
