Physical
Width: 320 mm (12.6 in.)
Width with multi-function bracket: 397 mm (15.6 in.)
Height: 350 mm (13.8 in.)
Height with multi-function bracket: 407 mm (16.0 in.)
Depth: 176 mm (6.9 in.)
Weight: 8.5 kg (18.7 lb.)
Performance
Maximum airflow: 1815m3 (65 000 ft3 ) hour
CFM: 1083 CFM
Fan speed: 200-2500 rpm
Noise level (max): 70 dBA
Control and Programming
Control options: Included analog timer remote control, DMX, test switch
Control parameters: Instant or timer-controlled output
Fan: Variable output, 0-100%
Remote cable: 3-pin XLR, includes 3 m (9.8 ft.), maximum length 50m (164 ft.)
DMX channels: 1
DMX compliance: ANSI E1.11 - USITT DMX512-A
Construction
Housing: Steel
Color: Black
Fan: 12” Sealed axial motor
Multi-function bracket: Integrated yoke w/safety attachment point
Installation
Mounting: Floor or hanging
Orientation: Any
Minimum clearance around machine: 101 mm (4 in.)
Connections
AC Power, EU: IEC male inlet, C14
AC Power, US: Hardwired mains, 3 m (9.8 ft.), NEMA 5-15P
DMX in/out: 3- and 5-pin locking XLR
Remote control: 3-pin locking XLR
|
Electrical
EU Model
AC Power: 220-240 V, 50/60 Hz
Fuse: 5 AT (slow-blow), 250 V
Typical power and current: 120 W, 0.53 A*
US Version
AC Power: 100-130 V, 50/60 Hz
Fuse: 3.15 AT (slow blow), 125 V
Typical power and current: 175 W, 1.48 A*
Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Thermal
Minimum ambient temperature: 0° C (32° F)
Maximum ambient temperature: 55° C (131° F)
Approvals
EU Model
EU safety: BS EN 60335-1+A15
EU EMC: EN 61000-6-3
EU immunity: EN 61000-6-1
Australia/NZ (pending): RCM
US Model
US safety: UL Std. 507 - 9th edition + R:04
Canada safety: CSA C22.2 No.113:2015
CE ETL C US Intertek
Included Items
Analog timer remote control, 3 m (9.8 ft.) cable: P/N 92765022
Power input cable, EU, IEC C13 female, stripped ends, 1.5 m (4.9 ft.): P/N 11501012
Multi-function bracket and hardware
Accessories
Installation Accessories
Half-coupler clamp: P/N 91602005
G-clamp (vertical hanging suspension only): P/N 91602003
Quick trigger clamp (vertical hanging suspension only): P/N 91602007
Safety cable, SWL 60 kg, BGV C1/ DGUV 17, black: P/N 91604006
Service Tools
Epsilon 5 AVR Programmer: P/N 50502004
|
