Lavonce WSN061.52 6.5 inç 80W Hoparlör
Lavonce WSN061.52 6.5 inç 80W Hoparlör
Lavonce WSN061.52 6.5 inç 80W Hoparlör

Lavoce WSN061.52 6.5 inç 200W Hoparlör

Marka : Lavoce
Fiyat : $148.80(KDV Dahil)

Lavoce WSN061.52 6.5 inç 200W Hoparlör

Çıplak Hoparlör katagorisinde yer alan , Lavoce WSN061.52 fiyat performans olarak on plana cıkmaktadır, column hoparlörlerde kullanılabilir,

en uygun lavoce WSN061.52'i www.medumuzikmarket.com'dan satın alabilirsiniz.



1,5 INCH COPPER VOICE COIL
94 dB/SPL SENSITIVITY



  GENERAL SPECIFICATIONS
Nominal diameter mm (in) 165 (6.5)
Nominal Impedance Ohm 8
Minimum impedance Ohm 6,4
Program power W 250
AES Power rating W 125
Sensitivity dB 94
Frequency range Hz 90 ÷ 6000
Voice coil diameter mm (in) 38 (1.5)
Chassis material   Steel
Magnet material   Neodymium
Magnet dimensions OD x ID x h mm (in) 75 x 45 x 4 (2.95 x 1.77 x 0.16)
Coil material   Copper
Former material   Polyimide
Cone material   Water Resistant Treated Paper
Surround material   Polycotton
Xmax mm (in) 3,8 (0.15)
Xmech mm (in) 6,3 (0.25)
Gap height mm (in) 6 (0.24)
Voice coil winding height mm (in) 10,6 (0.42)
Driver displacement volume l (ft³) 0,3 (0.01)
Recommended Enclosure l (ft³) 10,5 (0.37)
Recommended Tuning Hz 90
  SMALL SIGNAL PARAMETERS
DC resistance (Re) Ohm 5,5
Resonance frequency (Fs) Hz 91
Moving mass (Mms) g (oz) 13,37 (0.47)
Compliance (Cms) mm/N 0,23
Force factor (Bxl) N/A 6,66
Mechanical Q-factor (Qms)   7,14
Electrical Q-factor (Qes)   0,45
Total Q-factor (Qts)   0,42
Equivalent air volume (Vas) l (ft3) 6,66 (0.24)
Voice coil inductance (Le) mH 0,41
Diaphragm area (Sd) cm2 (in.2) 143,1 (22.17)
Reference efficiency (Eta 0)   1,07 %
Efficiency bandwidth product (EBP) Hz 202
  SHIPPING INFORMATION
Net weight kg (lb) 0,9 (2)
Multipack size W x D x H mm x mm x mm (in x in x in) 410 x 370 x 208 (16.1 x 14.6 x 8.2)
Multipack weight kg (lb) 9,9 (21.9)
