Lavoce FSN020.72 2 inç 30W Hoparlör
Lavoce FSN020.72 2 inç 30W Hoparlör
Lavoce FSN020.72 2 inç 30W Hoparlör

Lavoce FSN020.72 2 inç 30W Hoparlör

Marka : Lavoce
Fiyat : $31.28(KDV Dahil)

Lavoce FSN020.72 2 inç 30W Hoparlör

Çıplak Hoparlör katagorisinde yer alan , Lavoce FSN020.72 fiyat performans olarak ön plana cıkmaktadır, column hoparlörlerde kullanılabilir,

en uygun lavoce FSN020.72'yi www.medumuzikmarket.com'dan satın alabilirsiniz.

0.75 INCH CCAW VOICE COIL
84,5 dB/SPL SENSITIVITY



GENERAL SPECIFICATIONS
Nominal diameter mm (in) 50 (2)
Nominal Impedance Ohm 8
Minimum impedance Ohm 6,6
Program power W 30
AES Power rating W 15
Sensitivity dB 84,5
Frequency range Hz 200 ÷ 20000
Voice coil diameter mm (in) 20 (0.75)
Chassis material   Steel
Magnet material   Neodymium
Magnet dimensions OD x ID x h mm (in) 19 x 5 + 19 x 3 (0.75 x 0.2 + 0.75 x 0.1)
Coil material   CCAW
Former material   Polyimide
Cone material   Water Resistant Treated Paper
Surround material   Rubber
Xmax mm (in) 2,4 (0.09)
Xmech mm (in) 2,7 (0.11)
Gap height mm (in) 3 (0.12)
Voice coil winding height mm (in) 6,3 (0.25)
Driver displacement volume l (ft³) 0,03 (0.001)
Recommended Enclosure l (ft³) 0,78 (0.027)
Recommended Tuning Hz sealed
SMALL SIGNAL PARAMETERS
DC resistance (Re) Ohm 5,8
Resonance frequency (Fs) Hz 210
Moving mass (Mms) g (oz) 1,44 (0.05)
Compliance (Cms) mm/N 0,399
Force factor (Bxl) N/A 3,19
Mechanical Q-factor (Qms)   4,42
Electrical Q-factor (Qes)   1,16
Total Q-factor (Qts)   0,92
Equivalent air volume (Vas) l (ft3) 0,17 (0.01)
Voice coil inductance (Le) mH 0,063
Diaphragm area (Sd) cm2 (in.2) 17,4 (2.7)
Reference efficiency (Eta 0)   0,13 %
Efficiency bandwidth product (EBP) Hz 181
SHIPPING INFORMATION
Net weight kg (lb) 0,15 (0.34)
Multipack size W x D x H mm x mm x mm (in x in x in) 440 x 397 x 182 (17.3 x 15.6 x 7.2)
Multipack weight kg (lb) 12,8 (28.2)
