dB Technologies LVX XM15 15 inch 1200 Watt Peak Aktif Sahne Monitörü
Technical Data
Speaker Type2-Way Active Coaxial Stage Monitor
Acoustical data
Frequency Response [- 6 dB]58 - 17,800 Hz
Max SPL128 dB
HF1 " Exit 1,4" v.c.
Directivity (HxV)90° x 70°
LF15", 2,5 v.c.
Amplifier
Amp TechnologyDigipro® G3
Amp ClassClass D
Power RMS600 W
Peak Power1200 W
Power Supply SMPS with PSU Auto-range
Power Connection PowerCon In/Link
Cooling Convection
Processor
ControllerDSP 56 bit
Converter AD/DA24 bit/48 kHz
System Presets8 presets
LimiterPeak, RMS, Thermal
Processing (filters)FIR Linear Phase
Controls Rotary 8 positions,
MIC/LINE switch
Input
Mains Connections PowerCON in/link
Signal Input 1xCombo IN (XLR/Jack)
Signal Output1xXLR link OUT
USB connector Mini USB B-Type (service only)
Mechanics
HousingPlywood with black PVC Cover
Grille Metal, black painted
Handles2, chassis integrated
Pole Mount D36 mm
Width640 mm (25.20 in)
Height460 mm (18.11 in)
Depth370 mm (14.57 in)
Weight22,3 kg (49.16 lbs)
