dB Technologies DVA MS12 Aktif 12 inç 1400W Peak Asılabilir Subwoofer
Technical Data
Speaker TypeActive bass reflex flyable subwoofer
Acoustical data
Frequency Response [-6dB]45 - 140 Hz
Frequency Response [-10dB]40 - 165 Hz
Max SPL131 dB
LF12"
Voice Coil LF3"
DirectivityOmnidirectional
Amplifier
Amp TechnologyDigipro® G3
Amp ClassClass D
Power Supply700W SMPS with PSU Auto-range (110V~ and 220V~)
LF Amp700 W RMS (1400 W Peak)
CoolingConvection
Processor
ControllerDSP 56 bit
AD/DA Converter24 bit/48 kHz
ControlsX-Over frequency selection, Phase selection (0° or 180°), Outputs mode selection (Link/X-over), Mini-USB type “B” port (service data)
LimiterDual active, RMS/Peak, Thermal
Crossover Frequency LF-HF90 - 120 Hz
LF X-over out slope24 dB/Octave
Mechanics
HousingMultiplex plywood - Polyurea painting
Handles1x left side, 1x right side
Feet4x Dual Position Reversable Feet (flying/stacking mode)
FittingsM20 screw for pole mount on top side, integrated hardware with fast lock mechanics
Width460 mm (18.1 in)
Height430 mm (16.9 in)
Depth385 mm (15.2 in)
Weight26.5 kg (58.4 lbs)
